500 Series

Product Highlights Audio-Specific Bluetooth Technology High-Fidelity D/A Converters Lossless Transmission Burr Brown Analog Signal Path Supports AAC, aptX & SBC Codecs

Product Highlights For 500 Series Rack Modules LED Current Metering 150% More Power for 10-Space Chassis Solid Steel Construction Accommodates Various Manufacturer Units VCA Buss-Link Function Enabled in Pairs

Product Highlights 8 Available Spaces Each Slot Has Own Linear Power Supply Isolates Each Module From One Another Test LEDs For Checking Power 140mA of Phantom Gold Plated XLR I/O Heavy Gauge Steel Enclosure Made in the United Kingdom Dual Concentric Pan and Fader Controls VU Meter and Stereo Master Fader

Product Highlights 10 Available Spaces Each Slot Has Own Linear Power Supply Isolates Each Module From One Another Test LEDs For Checking Power 140mA of Phantom Gold Plated XLR I/O Heavy Gauge Steel Enclosure Made in the United Kingdom

Product Highlights 4 Available Spaces Each Slot Has Own Linear Power Supply Isolates Each Module From One Another Test LEDs For Checking Power 80mA of Phantom Gold Plated XLR I/O Heavy Gauge Steel Enclosure Made in the United Kingdom

Product Highlights Fits API 500 Series Lunchbox 80 dB Class A Microphone Preamplifier 10 dB Class A Bridgeable Line Amplifier Balanced and Floating Input Impedance HF Baxandall Shelf: 12,000 Hz LF Baxandall Shelf: 35, 60, 110, 220 Hz Classic 1073 Mid Frequency EQ High-Pass Filter EQ Button for Toggling On and Off Phase Button Flips Signal 180 Degrees

Product Highlights +6 to -20 dB Class A Line Level Preamp ± 16 High Frequency Shelving EQ ± 16 Low Frequency Shelving EQ ± 18 Mid Frequency Peaking EQ Equalizer Engage Button Class A 2N3055 High Headroom Output Internal Slow Turn-On Power Supply Uses Carnhill Transformers Classic Marconi Style Knobs 3-Band Equalizer from the 1073

Product Highlights Mic Preamp or Compressor Functions 60 dB 1073 Preamp Design 2264E-Style Compressor Stepped Rotary Switches Line & Mic Inputs High-Pass Filter for Pre & Compressor Requires 500 Series Chassis

Product Highlights 1U Module Fits API 500 Series Lunchbox 80 dB Class A Microphone Preamplifier 50 dB Class A Bridgeable Line Amplifier Balanced and Floating Input Impedance 20 dB Microphone Attenuation Pad 18 dB per Octave 80 Hz High-Pass Filter Internal Slow Turn-On +24V Power Supply 3 Gain Stage Modular Card Construction Carnhill Input and Output Transformers Marconi-Style Knobs and Engraved Buttons

Product Highlights 150% Available Current for Six Spaces Eight Channels LED Power Metering Double Shielded PSU to Manage Induction Balanced DB-25, XLR, and TRS Connections Versatile Interchangeable THRU Functionality on Channels 7-8 Solid Steel Construction Collapsible Handle Variable Position Crew Holes

The Maag Audio EQ4® (500 Series) is a one channel 6 band equalizer with AIR BAND® (shelf boost from 2.5 to 40kHz)

Product Highlights Single Channel Red Silk Circuit Adds Texture Variable High-Pass Filter Trim and Gain Knobs 48V Phantom Power Polarity Switch For 500 Series Racks

Product Highlights Single Channel Feed-Forward/Feed-Back Modes Peak/RMS Detection Side Chain High-Pass Filter -6 dB to +20 dB of Gain Adjustable Attack and Release Times Level and Gain Reduction Meters Stereo Link Ducking Available with Two 543 Modules Requires 500 Series Power Supply

Product Highlights Single-Channel, Transformer-Coupled 66dB of Mic Gain Silk "Warmth and Presence" Process Balanced or Unbalanced Hi-Z Input 30dB of DI Gain Opto-Coupler 2:1 Ratio Compressor Variable Phase 48V Phantom Power Ground Lift Requires 500 Series Power Supply

Rupert Neve Designs 551 Inductor EQ

Product Highlights Fits 500 Series Lunchbox Mic, Instrument, & Line Inputs Up to 71 dB of Gain Output Gain Attenuator Switchable Discrete Op Amp Switchable Input Impedance Switchable Output Transformer Switchable Capacitor 48V, Polarity Switch, 20 dB Pad

Warm Audio 500 Series WA12-500 MKII Dual-Transformer Microphone Preamplifier
