>> Hướng dẫn đặt hàng trực tuyến

Giá có thể thay đổi chưa kịp cập nhật, xin vui lòng liên hệ trực tiếp để biết giá

Tên thiết bị:  Bộ Lenovo ThinkPad Thunderbolt 3 Dock Gen 2 (135W)

Model:   40AN0135

Thương hiệu:  Lenovo Thinkpad

Tình trạng: đóng hộp, hàng mới, chính hãng 100%

Thời gian đặt hàng: 1 - 2 ngày

Hình ảnh thiết bị như hình chụp

  • Thunderbolt 3 Host & Accessory Ports
  • 2 x HDMI | 2 x DisplayPort
  • 5 x USB 3.1 Gen 2 Type-A
  • 1 x USB 3.1 Gen 2 Type-C Port
  • 1 x Gigabit Ethernet Port
  • 1 x 3.5mm Headphone/Mic Combo Jack
  • Security Lock Slot
  • Supports Three UHD Displays
  • Includes AC Adapter & Thunderbolt Cable
  • Windows 10 & 7 Compatible

Lenovo 40AN0135 Overview

With the ThinkPad Thunderbolt 3 Dock Gen 2 from Lenovo, you can connect a variety of peripherals directly to your ThinkPad laptop and other USB Type-C/Thunderbolt 3 enabled devices. This dock connects to your compatible host system using a Thunderbolt 3 port, and is built with a variety of other video inputs, including two HDMI outputs and two DisplayPort outputs that support up to three Ultra HD 4K displays.

Accompanying the video inputs, you will find a single Thunderbolt 3 port that supports the 10 Gb/s USB 3.1 Gen 2 standard. If that's not enough, this dock comes equipped with five 10 Gb/s USB 3.1 Gen 2 Type-A ports, one of which supports always-on charging.

The ThinkPad Thunderbolt 3 Dock Gen 2 has a single Gigabit Ethernet port, 3.5mm combination stereo/mic jack, and security lock slot. This dock comes with a 135W power adapter, a power cord, and a Thunderbolt 3 cable. Furthermore, this dock is compatible with Windows 10 and 7 operating systems.

General Features

Thunderbolt 3 Connectivity

This dock offers one Thunderbolt 3 port to connect and charge your computer. It is designed to transfer data at a rate up to 40 Gb/s.

4K Display Support

This dock features a built-in DisplayPort that can drive any display up to 4K resolution. Better yet, simultaneously connect a second 4K display to the USB Type-C port and enjoy enhanced productivity.

USB Type-C and Thunderbolt Expansion

  • Dual Ultra HD displays
  • Enhanced performance with professional video solutions and exclusive network manageability

Compatibility

  • ThinkPad X1 Yoga 2nd Gen (Machine Types: 20JD, 20JE, 20JF, 20JG)
  • ThinkPad X1 Yoga 3rd Gen (Machine Types: 20LD, 20LE)
  • ThinkPad T570 (Machine Types: 20H9, 20HA, 20JW, 20JX)
  • ThinkPad P51s (Machine Types: 20HB, 20HC, 20JY, 20K0)
  • ThinkPad T580 (Machine Types: 20L9, 20LA)
  • ThinkPad P52s (Machine Types: 20LB, 20LC)

Lenovo 40AN0135US Specs

Connections
USB 5 x USB 3.1 / USB 3.2 Gen 2 Type-A
Thunderbolt 1 x Thunderbolt 3
Ethernet 1 x RJ45 (10/100/1000 Mb/s)
FireWire None
Display 2 x HDMI
2 x DisplayPort
Audio 1 x 1/8" / 3.5 mm Headphone/Microphone Combo
Memory Card Slots None
Host Connections
System Connection 1 x Thunderbolt 3 Female
Connection Type Detachable Cable
Interface Max Data Rate 40 Gb/s
10 Gb/s
General
Chipset Intel Thunderbolt
Number of Displays Supported 3
Maximum Resolution Supported 3840 x 2160
Compatibility Lenovo ThinkPad X1 Yoga 2nd Gen
Lenovo ThinkPad X1 Yoga 3rd Gen
Lenovo ThinkPad T570
Lenovo ThinkPad T580
Lenovo ThinkPad P51s
Lenovo ThinkPad P52s
Operating System Support Windows
UASP Support No
Power
Power Source AC Adapter
Power Port Barrel Connector (Unspecified Diameter)
Environmental
Certifications FCC, cUL, as per Manufacturer
Operating Temperature 32 to 104°F / 0 to 40°C (Recommended)
Operating Humidity 5 to 95% (Recommended)
Physical
Lock Slot Yes
Dimensions 8.66 x 3.15 x 1.18" / 220 x 80 x 30 mm
Weight 1.16 lb / 525 g
Packaging Info
Package Weight 2.9 lb
Box Dimensions (LxWxH) 10.9 x 6.5 x 3"



In the Box

  • Lenovo ThinkPad Thunderbolt 3 Dock Gen 2 (135W)
  • 135W AC Adapter
  • Power Cord
  • Thunderbolt 3 Cable
  • Limited 1-Year Warranty
Bình chọn sản phẩm: (1.0 / 3 Bình chọn)
