Tên thiết bị:  Bộ âm thanh không dây Pyle Pro PDWM3400 UHF. Tần số 673 to 697.975 MHz

Model:   PDWM3400

Thương hiệu:  Pyle Pro

Tình trạng: đóng hộp, hàng mới, chính hãng 100%

Thời gian đặt hàng: 1 - 2 ngày

Hình ảnh thiết bị như hình chụp


Product Highlights

  • Up to Eight Selectable Channels
  • Up to 164' Operating Range
  • Balanced XLR and 1/4" Output
  • Independently Adjustable Volume Controls
  • PLL Synthesis
  • LED Power Indicator and Channel Display
  • RF Signal Indicator
  • Audio Level Indicator
  • Two Bodypack Transmitters
  • Two Headset and Two Lavalier Microphones



Overview:



The 673 to 697.975 MHz Pyle Pro PDWM3400 UHF Wireless Microphone System with Two Bodypacks, Two Headset Microphones, and Two Lavalier Microphones (673 to 697.975 MHz) is designed for recording and live sound reinforcement applications such as for concerts, theater, fitness classes, public speaking, and more. The system consists of a UHF wireless receiver that utilizes the phase lock loop-synthesized control technique to offer two simultaneous audio channels on eight selectable UHF transmission channels between 673 and 697.975 MHz. Two foldable and adjustable antennas help provide a reception range of 164'. Multiple systems can be used in the same area on different channels without interference.

The front panel of the receiver features a power button, and channel selector buttons for audio channels A and B, as well as radio frequency and audio level indicator lights. The back of the panel features volume control knobs for channels A and B, as well as a balanced XLR output connector and an unbalanced 1/4" phone output connector.

The system comes with two bodypack transmitters with channel selector controls and displays, as well as a low battery warning indicator light. Each transmitter is powered by two AA batteries. For capturing vocals, the system also includes two hands-free headset microphones and two lavalier microphones with built-in clothing clips.



Ultra-High Frequency (UHF) Transmission
Provides a larger transmission range than VHF systems
Front-Panel Control
Provides adjustable volume control, RF indicator, AF indicator, power indicator, power switch, and channel frequency display
PLL Synthesis
Provides eight selectable UHF channels
RF Signal Indicator LED
Illuminates when the receiver is receiving a radio signal from the transmitter(s)
AF Signal Indicator LED
Illuminates when the system is receiving an audio signal
Low Battery Warning
Illuminates red when one hour of battery life remains
Output Jacks
Features unbalanced 1/4" phone plug and balanced XLR output connectors for connection to a range of external devices
Multiple System Use
Enables simultaneous use of multiple UHF systems on different frequency bandwidths



Specifications:SystemSystemSystemSystem


Operation Range 164'
Channels Up to eight UHF channels
Output 1x 1/4" TRS Phone jack
1x balanced XLR jack
Power Supply 110/220 V
Receiver
RF Frequency Range 673 to 697.975 MHz
Image & Spurious Rejection > 70 dB
Receiving Sensitivity -105 dB
Signal / Noise -105 dB
Border Upon Channel Rejection > 70 dB
THD < 1%
Audio Output Level 0 to 300 mV
Power Requirements 13 to 15 VDC nominal 500 mA
Dimensions (W x D x H) 6.80 x 5.30 x 1.70" (17.3 x 13.5 x 4.32 cm)
Weight Not specified by the manufacturer
Bodypack Transmitter
RF Frequency Range 673 to 697.975 MHz
RF Output > 10 dBm
Modulation FM
Deviation ± 40 kHz
Spurious Emission > 55 dBc
Current < 40 mA
Power Requirements 2x 1.5 V AA (not included)
Packaging Info
Package Weight 2.55 lb
Box Dimensions (LxWxH) 11.6 x 7.6 x 4.6"



In the Box:

Pyle Pro PDWM3400 UHF Wireless Microphone System with Two Bodypacks, Two Headset Microphones, and Two Lavalier Microphones (673 to 697.975 MHz)
  • UHF Receiver
  • 1/4" to 1/4" Audio Cable
  • AC/DC Power Adapter
  • 2 x Bodypack Transmitters
  • 2 x Headsets
  • 2 x Lavalier Microphones
  • Limited 1-Year Warranty
