Dynaudio Acoustics M3XE Pack - 12

Overview:

• M3XE - 12" Three-Way Passive Monitor (Right-Side)



  The M3XE 12" Three-Way Passive Monitor from Dynaudio Acoustics is a right-channel studio monitor speaker, ideal for use in professional studios. Unlike the M3VE, a pair of M3XE speakers is designed to be matched with two 4-channel Lab.gruppen PLM 12k44 amplifiers (available separately). Each amplifier allows the monitor to use the integrated Lake active-crossover process as well as power the HF, MF and dual LF woofers with the four independent amplifier channels of the 12k44. With Dynaudio ESOTAR driver technology, the monitor supports frequency response of 22 Hz to 21 kHz and SPL of 135 dB.



  Note: Amplifier unit is not included.

  Three-way main monitor

  Dual 12" ESOTAR woofers, aluminum voice coil

  Dual 6" midrange drivers, MSP cone, 75mm aluminum voice coil

  1.1" ESOTAR soft-dome tweeter, aluminum voice coil

  Handcrafted drivers

  Passive MF/HF crossover

  A pair is designed to be matched with two (2) Lab.gruppen PLM 12k44 amplifiers (available separately)

  Linear phase frequency response

  Maximum SPL of 135 dB SPL

  Heavy internal damping for minimum cabinet resonance

  For in-wall or free-standing setups

  Made in Denmark

• M3XE - 12" Three-Way Passive Monitor (Left-Side)



  The M3XE 12" Three-Way Passive Monitor from Dynaudio Acoustics is a left-channel studio monitor speaker, ideal for use in professional studios. Unlike the M3VE, a pair of M3XE speakers is designed to be matched with two 4-channel Lab.gruppen PLM 12k44 amplifiers (available separately). Each amplifier allows the monitor to use the integrated Lake active-crossover process as well as power the HF, MF and dual LF woofers with the four independent amplifier channels of the 12k44. With Dynaudio ESOTAR driver technology, the monitor supports frequency response of 22 Hz to 21 kHz and SPL of 135 dB.



  Note: Amplifier unit is not included.

  Three-way main monitor

  Dual 12" ESOTAR woofers, aluminum voice coil

  Dual 6" midrange drivers, MSP cone, 75mm aluminum voice coil

  1.1" ESOTAR soft-dome tweeter, aluminum voice coil

  Handcrafted drivers

  Passive MF/HF crossover

  A pair is designed to be matched with two (2) Lab.gruppen PLM 12k44 amplifiers (available separately)

  Linear phase frequency response

  Maximum SPL of 135 dB SPL

  Heavy internal damping for minimum cabinet resonance

  For in-wall or free-standing setups

  Made in Denmark

Specifications:

• M3XE - 12" Three-Way Passive Monitor (Right-Side)

  Speaker
  Type	3-way passive main monitor
  Frequency Response ± 3dB	22 Hz to 21 kHz
  Max Peak SPL	> 135 dB peak @ 3.3' (1.0 m)
  Amplifier	A pair is designed to be matched with two (2) Lab.gruppen PLM 12k44 amplifiers (available separately)
  Resonance	24 Hz
  Cabinet Volume	145 liters
  Bass Principle	Bass reflex
  Tweeter	ESOTAR 1.1" (2.8 cm) soft dome magnetic fluid, metal rear chamber, pure-aluminum-wire voice coil, 0.2" (0.4 cm) die-cast-aluminum front, neodymium magnet material
  Mid-Range Unit	6" (15 cm) with 2.9" (7.5 cm) diameter, pure-aluminum-wire voice-coil, one-piece molded MSP cone
  Woofer	ESOTAR 12" (30 cm) with 2.9" (7.5 cm) diameter, pure-copper-wire voice-coil, MSP-cone, long stroke
  Crossover	All 4 Channels: Active DSP-based in-amp Lake processor; each channel has impedance-correction providing the best working conditions for the amplifier
  Cabinet	1" (25 mm) MDF, strategically braced and damped; low-turbulence reflex ports; separate chambers for each woofer
  Dimensions	21.9 x 30.5 x 19.9" (55.5 x 77.5 x 50.5 cm)
  Weight	143 lb (65 kg)

• M3XE - 12" Three-Way Passive Monitor (Left-Side)

  Speaker
  Type	3-way passive main monitor
  Frequency Response ± 3dB	22 Hz to 21 kHz
  Max Peak SPL	> 135 dB peak @ 3.3' (1.0 m)
  Amplifier	A pair is designed to be matched with two (2) Lab.gruppen PLM 12k44 amplifiers (available separately)
  Resonance	24 Hz
  Cabinet Volume	145 liters
  Bass Principle	Bass reflex
  Tweeter	ESOTAR 1.1" (2.8 cm) soft dome magnetic fluid, metal rear chamber, pure-aluminum-wire voice coil, 0.2" (0.4 cm) die-cast-aluminum front, neodymium magnet material
  Mid-Range Unit	6" (15 cm) with 2.9" (7.5 cm) diameter, pure-aluminum-wire voice-coil, one-piece molded MSP cone
  Woofer	ESOTAR 12" (30 cm) with 2.9" (7.5 cm) diameter, pure-copper-wire voice-coil, MSP-cone, long stroke
  Crossover	All 4 Channels: Active DSP-based in-amp Lake processor; each channel has impedance-correction providing the best working conditions for the amplifier
  Cabinet	1" (25 mm) MDF, strategically braced and damped; low-turbulence reflex ports; separate chambers for each woofer
  Dimensions	21.9 x 30.5 x 19.9" (55.5 x 77.5 x 50.5 cm)
  Weight	143 lb (65 kg)
