>> Hướng dẫn đặt hàng trực tuyến
Giá có thể thay đổi chưa kịp cập nhật, xin vui lòng liên hệ trực tiếp để biết giá
Tên thiết bị: Card âm thanh thu âm Tascam UH-7000 USB
Model: Tascam UH-7000
Thương hiệu: Tascam Japan
Tình trạng: đóng hộp, hàng mới, chính hãng 100%
Thời gian đặt hàng: 1 - 2 ngày
Hình ảnh thiết bị như hình chụp
Product Highlights
- 4-in/4-out USB Interface
- Can Be Used as Standalone Preamp
- AES/EBU Digital I/O
- XLR and TRS Inputs
- Stereo XLR Analog Outputs
- 24-bit/192kHz AD/DA Conversion
- Burr-Brown PCM4220/1795 AD/DA Converters
- HDIA Mic Preamps: -128dB EIN
- Built-In DSP Mixer Effects
- Mac and Windows Compatible
Overview:
-
The Tascam UH-7000 is a pro-level USB interface for Mac and Windows that can also be used as a standalone mic preamp. It features built-in DSP mixer effects, supports 24-bit/192kHz USB transmission and AD/DA conversion, and is housed in a rugged metal casing for durability.
The UH-7000 is equipped with two HDIA (High Definition Instrumentation Architecture) microphone preamps that are designed to perform at −128dBu EIN, a 117dB signal-to-noise ratio and distortion ratio of 0.0009% or less. The Burr-Brown PCM4220 AD and PCM1795 DA converters allow for high-quality conversion, ensuring optimal sound reproduction for recording and monitoring. - Features:
-
- Two 20-segment LED level meters
- Standard TRS headphones output jack - 45mW/channel output
- +48 Phantom power supply
- Two pairs of balanced analog XLR jacks for both input and output
- Professional output specifications (maximum output level: +24 dBu)
- Two balanced analog TRS input jacks
- XLR digital input and output jacks support AES3-2003/IEC60958-4 (AES/EBU) and IEC60958-3 (S/PDIF) formats
- Three-pronged inlet power cable
- Half-rack size
- Confirmed operation with major DAW software, including Sonar X3, ProTools, Cubase and Live
- RoHS CompliantThin film metal resistors with outstanding noise performance
- Thin film metal resistors with outstanding noise performance
- High audio quality film capacitors with low distortion
- Low latency monitoring through the DSP mixer
- DSP mixer can be switched between multitrack and stereo mix modes
- DSP mixer enables independent adjustment of recording and monitoring levels
- Line or digital outputs can be selected using the DSP mixer
- DSP dynamics effect can be applied to inputs, outputs or the master (compressor, noise suppressor, de-esser, exciter, EQ, limiter/low cut)
- DSP REVERB (hall, room, live, studio, plate) send effect is perfect for monitoring when recording
- Link line function enables volume control of powered monitors
- Single punch MIXER PANEL button
- Strong, durable aluminum body
- Large INPUT level knobs enable precise adjustment of input levels
UPC: 043774030170
Specifications:
| Sampling Frequencies | 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz |
| Bit Depth | 24-bit |
| Line Input | Connector: 1/4" (6.3 mm) TRS jack, (T:hot, R:cold, S:ground), balanced Input Impedance: 15 kohms Maximum Input Level: +26.5dBu Minimum Input Level: -38dBu |
| Mic Input | Connector: XLR-3-31, (1:ground, 2:hot, 3:cold), balanced Input Impedance: 2.2 kohms Maximum Input Level: +2 dBu Minimum Input Level: -60 dBu |
| Line Output | Connector: XLR-3-32, (1:ground, 2:hot, 3:cold), balanced Output Impedance: 100 ohms Maximum Output Level: +24 dBu |
| AES/EBU Audio Input | Connector: XLR-3-31, (1:ground, 2:hot, 3:cold) Formats: IEC60958-3 (S/PDIF), IEC60958-4 (AES/EBU) Sampling Frequencies: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz |
| AES/EBU Audio Output | Connector: XLR-3-32, (1:ground, 2:hot, 3:cold) Formats: IEC60958-3 (S/PDIF), IEC60958-4 (AES/EBU) Sampling Frequencies: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz |
| Phones | Connector: 1/4" (6.3 mm) stereo phone jack Maximum Output: 45 mW + 45 mW or more (THD+N 1% or less, 32 ohms loaded) |
| USB | Connector: USB B type 4-pin Format: USB 2.0 high speed (480 Mbps), full speed (12 Mbps) |
| Power | AC 100 - 240 V, 50 / 60 Hz |
| Power Consumption | 15 W |
| Audio Performance | ADC Chipset Dynamic Range: 123dB (A-weighted) DAC Chipset Dynamic Range: 123dB (A-weighted) Frequency Response: 20Hz to 80kHz +0.005dB/-0.16dB (mic preamp for all sampling frequencies) THD: 0.0009% or less(MIC to AD) S/N Ratio: 117dB (MIC to AD) EIN: -128dBu |
| Windows Requirements | Compatible OS:
Windows XP: 32-bit SP3 or later Windows 7: 32/64-bit SP1 or more Windows 8: 32/64-bit Windows 8.1: 32/6-4bit *Windows Vista and Windows XP 64-bit are not supported.
Compatible Computers: Windows-compatible computer with a USB 2.0 port
CPU Type/Speed: Dual core/2 GHz or faster (x86)
Memory: 2 GB or more
Supported Audio Drivers: ASIO2.0, WDM (MME)
|
| Mac Requirements | Compatible OS:
Mac OS X Snow Leopard (10.6) OS X Lion (10.7) OS X Mountain Lion (10.8) OS X Mavericks (10.9)
Compatible Computers: Apple Macintosh computer with a USB 2.0 port
CPU Type/Speed: Dual core/2 GHz or faster
Memory: 2 GB or more
Supported Audio Drivers : Core Audio
|
| Dimensions | 8.4 ×3.2 ×9.2" (214.0 × 81.2 × 233.0 mm) |
| Weight | 4.85 lb (2.20 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 7.45 lb |
| Box Dimensions (LxWxH) | 15.7 x 13.5 x 6.6" |
In the Box:
